Characteristic：
With a unique open fuselage structure, when opening the crushing room, there is no dead angle, easy to clean;
The grinding knife adopts a new cutting knife and has low rotating speed, thus reducing the generation of dust;
The body surface adopts electroless nickel plating, not only enhances the hardness of the crushing chamber, but also plays a rust prevention role, and does not fall off, and does not cause pollution to the crushing material;
The knife groove of the grinding knife can be simply and conveniently taken out;
The feeding door is made of shockproof stainless steel plate, which reduces the noise;
The full open structure of the crushing chamber does not need oiling, so it is easy to maintain;
The fine grinding cutter of the crusher adopts arc design, and the cutter tooth is not easy to break;
The screw discharge device at both ends of the spindle has the function of preventing dust from entering the bearings.
规格表
|
规格/型号 |
口径 |
工作能力 |
马达功率 |
机械尺寸 |
重量 |
轴心转速 |
|
YJM-201 |
220*165 |
8-10 |
1HP(0.75KW) |
600*410*880(1200) |
200 |
27-35 |
|
YJM-202 |
220*255 |
10-15 |
2HP(1.5KW) |
600*500*900(1200) |
250 |
27-35 |
|
YJM-203A |
260*255 |
10-20 |
3HP(2.2KW) |
600*590*920(1200) |
300 |
27-35 |
|
YJM-203B |
260*360 |
15-30 |
3HP(2.2KW) |
600*590*920(1200) |
300 |
27-35 |
|
YJM-205A |
260*360 |
15-30 |
5HP(3.7KW) |
600*590*920(1200) |
300 |
27-35 |
|
YJM-205B |
500*360 |
15-30 |
5HP(3.7KW) |
900*800*1200 |
350 |
27-35 |
Specifications, shapes and colours are subject to change without prior notice.
